MÄRKLIN PRODUCT: 39065 Diesel locomotive - class 77

AN EXTRACT FROM MODEL RAIL WORKSHOP - H0 MÄRKLIN DATABASE

Feel free to copy and use.....

KEY DATA
Product Name	39065 Diesel locomotive - class 77
Object type	Locomotive-Diesel
Product Line	Märklin
Era	2006 - (VI)
Manufactured years	2020-2022
Text on object	CROSSRAIL
Number on object	DE 6310
Classification	class 77
Type of housing	Metal
Length	24.7 cm
Technology	Digital MFX+
Nationality	Belgium
Railway company	- Crossrail
Märklin RRP (Year)	439€ (2021)
Url to Märklin	Klick to GoTo www.maerklin.de

Search for more products in the Database!

Description
Class 77 Diesel Locomotive Type JT42CWRM diesel electric freight locomotive, better known as Class 77. Crossrail, Inc. diesel locomotive. The locomotive looks as it did in 2012. Source: www.maerklin.de Tighter EU exhaust gas regulations starting on January 1, 2009 forced the American builder Electro-Motive Division (EMD) starting in 2005, to overhaul fundamentally the Class 66 (EMD JT42CWR) built for the European market. The history of this class began in 1985, when EMD (at that time a 100% subsidiary of General Motors) built an affordable diesel locomotive for the British market. Out of this came a six-axle, diesel-electric unit, the type EMD JT26CW-SS in an angular design and with a 2,460 kilowatt / 3,299 horsepower diesel motor, the GM 16-645E3C. The locomotive was designated as the Class 59. EMD used as a basis the American diesel locomotive, type SD40-2, built in large quantities due to its proven, simple construction, which had turned out very reliable. Initially for British railroads, EMD then overhauled and improved the Class 59 in the mid-Nineties as externally largely unchanged locomotives with a 2,350 kilowatt / 3,151 horsepower GM-Motor 12N-710G3B-EC as the Class 66 (type JT42CWR), which initially went into operation starting in 1998 at the British company EVU. Its diesel motor powered a three-phase generator, type M AR8/CA6, which provided electrical energy to the six series-wound commutator traction motors installed in the trucks and geared to the wheelsets using an axle-hung gearbox. The locomotive engineer sat on the left side instead of the right because the locomotives were planned only for use in Great Britain. By the end of 2005, the lower emissions variant emerged due to tighter EU exhaust gas regulations as type JT42CWRM (in Great Britain: JT42CWR-T1) with an improved and overall reliable 2,420 kilowatt / 3,299 horsepower diesel motor, type 12-710G3B-T2, for fuel efficiency. On several railroads, it was no longer rostered as the Class 66 but as the Class 77. These improved locomotives were given better sound insulation in the cab, improvements to safety and comfort for the engineer as well as optional air conditioning. Additional external accessories were now two-part cab side windows, larger vent louvers, as well as a third door on one side due to partial removal of the continuous side corridor in the locomotive body. Increased safety, improved adhesion, and a longer maintenance interval were achieved with the EMD HTCR-E radial truck. In addition, there was the EM2000TM microprocessor control system for load control, motor control, and adhesion control, whereby a diagnosis system and the memory storage of past runs was implemented at the same time. A total of 244 units were delivered of the improved variant JT42CWR(M/-T1) by the end of production in 2016. Many of these units belong to leasing firms such as the Porterbrook Leasing Company (5 units), Eversholt Rail (26 units), Beacon Rail Leasing (40 units), Macquarie European Rail (24 units), or Alpha Trains (7 units), which leased the locomotives to third parties in numerous European countries. There is thus a variety of paint schemes and lettering and they change constantly. Forty-one units went in 2009 to the roster of the Egyptian National Railways (ENR) and in 2011/12, six units enriched the Societé d´Exploitation Transgabonais (SETRAG) for service in Gabon in Africa. The Euro Cargo Rail (ECR), part of the DB group, acquired the most units currently with 60 JT42CWRM locomotives. They currently run for the most part as the class 247 for DB Cargo in Germany. Privately held EVU belongs to the owners of these locomotives such as the Belgian Crossrail (8 units), the French Akiem (10 units), and the British GB Railfreight (17 units).

Description

Class 77 Diesel Locomotive

Type JT42CWRM diesel electric freight locomotive, better known as Class 77. Crossrail, Inc. diesel locomotive. The locomotive looks as it did in 2012.

Source: www.maerklin.de
Tighter EU exhaust gas regulations starting on January 1, 2009 forced the American builder Electro-Motive Division (EMD) starting in 2005, to overhaul fundamentally the Class 66 (EMD JT42CWR) built for the European market. The history of this class began in 1985, when EMD (at that time a 100% subsidiary of General Motors) built an affordable diesel locomotive for the British market. Out of this came a six-axle, diesel-electric unit, the type EMD JT26CW-SS in an angular design and with a 2,460 kilowatt / 3,299 horsepower diesel motor, the GM 16-645E3C. The locomotive was designated as the Class 59. EMD used as a basis the American diesel locomotive, type SD40-2, built in large quantities due to its proven, simple construction, which had turned out very reliable. Initially for British railroads, EMD then overhauled and improved the Class 59 in the mid-Nineties as externally largely unchanged locomotives with a 2,350 kilowatt / 3,151 horsepower GM-Motor 12N-710G3B-EC as the Class 66 (type JT42CWR), which initially went into operation starting in 1998 at the British company EVU. Its diesel motor powered a three-phase generator, type M AR8/CA6, which provided electrical energy to the six series-wound commutator traction motors installed in the trucks and geared to the wheelsets using an axle-hung gearbox. The locomotive engineer sat on the left side instead of the right because the locomotives were planned only for use in Great Britain. By the end of 2005, the lower emissions variant emerged due to tighter EU exhaust gas regulations as type JT42CWRM (in Great Britain: JT42CWR-T1) with an improved and overall reliable 2,420 kilowatt / 3,299 horsepower diesel motor, type 12-710G3B-T2, for fuel efficiency. On several railroads, it was no longer rostered as the Class 66 but as the Class 77. These improved locomotives were given better sound insulation in the cab, improvements to safety and comfort for the engineer as well as optional air conditioning. Additional external accessories were now two-part cab side windows, larger vent louvers, as well as a third door on one side due to partial removal of the continuous side corridor in the locomotive body. Increased safety, improved adhesion, and a longer maintenance interval were achieved with the EMD HTCR-E radial truck. In addition, there was the EM2000TM microprocessor control system for load control, motor control, and adhesion control, whereby a diagnosis system and the memory storage of past runs was implemented at the same time. A total of 244 units were delivered of the improved variant JT42CWR(M/-T1) by the end of production in 2016. Many of these units belong to leasing firms such as the Porterbrook Leasing Company (5 units), Eversholt Rail (26 units), Beacon Rail Leasing (40 units), Macquarie European Rail (24 units), or Alpha Trains (7 units), which leased the locomotives to third parties in numerous European countries. There is thus a variety of paint schemes and lettering and they change constantly. Forty-one units went in 2009 to the roster of the Egyptian National Railways (ENR) and in 2011/12, six units enriched the Societé d´Exploitation Transgabonais (SETRAG) for service in Gabon in Africa. The Euro Cargo Rail (ECR), part of the DB group, acquired the most units currently with 60 JT42CWRM locomotives. They currently run for the most part as the class 247 for DB Cargo in Germany. Privately held EVU belongs to the owners of these locomotives such as the Belgian Crossrail (8 units), the French Akiem (10 units), and the British GB Railfreight (17 units).
