MÄRKLIN PRODUCT: 3341 Electric locomotive - Class Rc2/Rc3

AN EXTRACT FROM MODEL RAIL WORKSHOP - H0 MÄRKLIN DATABASE

Feel free to copy and use.....

KEY DATA
Product Name	3341 Electric locomotive - Class Rc2/Rc3
Object type	Locomotive-Electric
Product Line	Märklin
Era	1990-2006 (V)
Manufactured years	1993-1994
Type of housing	Synthetic
Length	17.5 cm
Technology	Analog/Relay/Delta
Nationality	Sweden
Railway company	- SJ Svenska Järnvägar
Koll valuation (Year)	95€ (2022)

Search for more products in the Database!

No	Obj.No	Obj.txt	Category	Description
-	Rc2 1056	SJ Rc2	Rc2	Electric locomotive - SJ- blue -17.5 cm (1992-1994)
-	Rc3 1061	SJ Rc3	Rc3	Electric locomotive - SJ- blue -17.5 cm (1995-1996)
-	Rc3 1061	SJ Rc3	Rc3	See description

Description
Edition: 1992-1994 : Locomotive number Rc 2 1056 The red-orange plastic housing has a dark-grey roof with dark-brown insulators. The roof lines are made of nickel-plated and red-lacquered wire. The mounted pantographs correspond to the type 9B. A cream colored wraparound trim line is at the bottom and a slightly wider one in the center of the locomotive. Furthermore, there is a decorative line that runs across the drivers cabs. The windows used are transparent and, with the exception of the portholes, have a silver frame. The shields on the sides in the middle are raised. All inscriptions and the SJ logo are printed in white. Also the existing drivers cab markings A and B is printed in white. The existing four-light peak signal, two lamps above and two below, changes with the direction of travel. The red lamp at the top center is red as a dummy and not functional. Blue plastic rear-view mirror replicas are located at the corners of the drivers cabs. The gray cast chassis has a powered bogie with four traction tires. The buffer beam is also grey. The decorative line above is red. The wheel sets consist of disc wheels with a black/grey background, which are covered by a medium-grey plastic cover. The locomotive has yellow rail clearers on each end. Edition: 1995 - 1996 : Locomotive number Rc 3 1061 Design like variant 3341.01, but the red decorative line is only in the front area and zigzags on the sides. The drivers cab markings A and B have been removed. The rail clearers were given a red color scheme in this variant. The model received a 4-dip delta decoder instead of the direction switch. Edition: 1995 - 1999 Locomotive number Rc 3 1061 Design like variant 1995-1996, but with the cab markings A and B. This locomotive was also included in the 28725 train set from 1998 - 1999.

Description

Edition: 1992-1994 : Locomotive number Rc 2 1056

The red-orange plastic housing has a dark-grey roof with dark-brown insulators. The roof lines are made of nickel-plated and red-lacquered wire. The mounted pantographs correspond to the type 9B. A cream colored wraparound trim line is at the bottom and a slightly wider one in the center of the locomotive. Furthermore, there is a decorative line that runs across the drivers cabs. The windows used are transparent and, with the exception of the portholes, have a silver frame. The shields on the sides in the middle are raised. All inscriptions and the SJ logo are printed in white. Also the existing drivers cab markings A and B is printed in white. The existing four-light peak signal, two lamps above and two below, changes with the direction of travel. The red lamp at the top center is red as a dummy and not functional. Blue plastic rear-view mirror replicas are located at the corners of the drivers cabs.
The gray cast chassis has a powered bogie with four traction tires. The buffer beam is also grey. The decorative line above
is red. The wheel sets consist of disc wheels with a black/grey background, which are covered by a medium-grey plastic
 cover. The locomotive has yellow rail clearers on each end.

Edition: 1995 - 1996 : Locomotive number Rc 3 1061

Design like variant 3341.01, but the red decorative line is only in the front area and zigzags on the sides.
The drivers cab markings A and B have been removed. The rail clearers were given a red color scheme in this variant.
The model received a 4-dip delta decoder instead of the direction switch.

Edition: 1995 - 1999 Locomotive number Rc 3 1061
Design like variant 1995-1996, but with the cab markings A and B.
This locomotive was also included in the 28725 train set from 1998 - 1999.
